5 Different Types Of Epoxy Resin For Vertical Pipelining

Epoxy resin is a polyepoxide used as an adhesive in many industries. Due to its flexural integrity, there’s an industrial and domestic preference for epoxy resin. Depending on the application, the hardener and mixing ratio determines the curing time for epoxy resin.

For instance, the proportion of 4:1 for the epoxy to hardener will lengthen the curing time for the mixture. A lengthy curing period will give you enough time to complete your project. Therefore, to get the right results for your project, you must accurately measure the exact quantity of the epoxy and hardener.

Epoxy resins are expensive, and you must take precautions with measurements to avoid wastage. Accordingly, you should invest in a good weighing scale with better sensitivity. The Max US Scale Product is the industry standard weighing scale with an accuracy of a hundredth gram.

Epoxy Resin Pipelining

When mixed in the correct ratio, epoxy resin with a hardener provides an inexpensive solution for fixing broken pipes. Pipelining involves setting parts or longitudinal sections of leaking pipes. You can gently pour a gel-like mixture of epoxy resin into a broken pipe to coat the internal cross-section.

As the gel flows evenly inside the tube, it forms an interior coat that seals any holes and deformities in the host pipe. Depending on the resin to hardener ratio, the gel cures to form a continuous internal tube embedded in the host pipe. Vertical pipelining is similar to the cured-in-place manufacturing used to fix buried pipes.

Types Of Epoxy Resins

There are various epoxy resins on the market for pipelining based on your needs. Epoxy resins fall into two broad groups: glycidyl and non-glycidyl polyepoxides. The glycidyl polyepoxides are further subdivided into glycidyl-amines, glycidyl-ethers, and glycidyl-esters. Non-glycidyl polyepoxides can further be subdivided into aliphatic and cyclic-aliphatic subgroups.

The most commonly used polyepoxides are the glycidyl-ethers, especially the novolacs and bisphenols. Here are some types of epoxy resin:

• 1. Bisphenol Epoxy

Due to its low molecular weight, bisphenol polyepoxide is the most common epoxy resin for industrial use. It’s the final reaction product between bisphenol-A and epichlorohydrin with a catalyst. Bisphenol epoxy is less dense due to its low molecular weight.

Therefore, if your workshop and operation site are far apart, then you should consider this type of epoxy due to its long curing duration.

• 2. Novolac Epoxy

Novolac is a product of a contact reaction between formaldehyde and phenol. The good thing about novolacs is that they don’t contain harmful solvents or volatile compounds with carcinogenic properties. The reaction between epichlorohydrin and novolacs yields novolacs with glycidyl residues that could either be epoxy phenol novolac or epoxy cresol novolac.

A novolac epoxy should be on top of your list if you’re applying vertical pipelining on domestic water systems. Novolacs don’t emit harmful odors and are highly safe to use. In addition, there’s no risk of exposure, and it has high adhesive strength and good coverage in various applications. Furthermore, they’re durable.

• 3. Aliphatics Epoxy

An aliphatic polyepoxide is a product formed from the epoxidation of cycloaliphatic epoxides and epichlorohydrin. Aliphatics have a definite carbon structure and an oxirane but lack a chlorine atom. Aliphatics are less dense, resistant to weather changes, and highly resistant to electric current.

• 4. Halogenated Epoxy

Halogenation of polyepoxides with bromine, chlorine, or fluorine yields halogenated epoxies. The most common and preferred halogenated epoxy is brominated bisphenol-A due to its resistance to fire and insulating properties.

Unfortunately, due to associated costs, there’s little incentive for the industrial production of epoxy. You should consider halogenated epoxies if you’re vertical pipelining a gas supply system.

• 5. Epoxy Putties

Epoxy putties are commercial-grade polyepoxides that can harden at room temperature. Epoxy putties serve as space fillers on furniture, clean coating on commercial epoxy floors, and adhesives for vertical pipelining in piping systems.

Epoxy putty is a good option if you’re looking for a suitable coating agent for vertical pipelining in a DIY project. The ability to mix with hardeners and cure under room temperature means they’re suitable for domestic use. In the process, the new coat helps to fix cracks and leakages in the host pipe.

On the other hand, the composition of such epoxies varies based on manufacturers’ specifications and applications. They’re suitable for binding, pipelining, waterproofing, and providing structural support for various materials.

Conclusion

Learning about the different types of epoxy resins in the market is the first step towards proper vertical pipelining. There are five types of epoxy resins for industrial and home use. Whether you’re a professional or a hobbyist looking for advice on vertical pipelining, you need to know the suitability of each epoxy resin for your project.
